CHAPTER THREE
A blinking cursor appears at the presently selected IRIG code to be translated. The “.1”
indicates a 100Hz code and the “1K” indicates a 1KHz code. If the desired code has been
selected, pressing the NEXT switch will cause the Translating Menu, Figure 3.8.5.1 to be
displayed on the LCD Display.
If there is not a blinking cursor on this menu no IRIG code has been selected. If it is desired to
see what input code has been selected press the NEXT switch and the Translating Menu, Figure
3.8.5.1, will appear on the LCD Display showing the selected Translator code selected in the
upper right hand corner after “Translating”.
If the input code is different than that shown on the display, it is necessary to select the correct
code. Changing the code selection is accomplished by pressing the switch beneath the desired
code. When the new desired code is selected the LCD Display will change to that shown in
Figure 3.8.5.1 with the selected code being translated shown in the upper right hand corner of the
display.
The selection of SP1 or SP2 are reserved for translation of special codes, and the message
“Selected option is not installed…(See Figure 3.4.1) will appear. If either one of these special
codes are provided, its option description will be in Appendix A.
3.8.3 TRANSLATOR NASA CODE INPUT SELECTION
The Select Desired NASA Code Menu, Figure 3.8.2.1, is used to select the NASA code to be
translated. If the code has previously been selected, skip to the Translating Menu, Figure 3.8.5.1
by pressing NEXT. To select a code, push the corresponding switch.
Pressing the PREV switch while the Translating Menu is shown on the LCD Display will return
it to the Set-Up Translator Menu, Figure 3.8.3.
Select Desired NASA Code Menu
Figure 3.8.3.1
Select Desired NASA Code
28.1 28K 36
A blinking cursor will appear on the selected code to be translated. If the desired code has been
selected, pressing the NEXT switch will cause the Translating Menu, Figure 3.8.5.1 to be
displayed on the LCD Display.
If no blinking cursor appears on this menu, none of the NASA codes have been selected.
Pressing the
NEXT switch causes the Translating Menu Figure 3.8.5.1 to appear on the LCD
Display showing the selected Translator Code in the upper right hand corner after “Translating”.
Should the input code be different than that previously selected, it is necessary to select the
correct code. Selecting the correct code is accomplished by pressing the switch beneath the
desired code. When the new code selection is made, the LCD Display will change to that shown
in Figure 3.8.5.1 with the selected code being translated shown in the upper right hand corner of
the display.
3-22 TM7000 TymMachine TCG/T (Rev D) Symmetricom, Inc.
