OPTION DESCRIPTIONS
TM Option 32 Distribution Module, 600Ω Driver Assembly 20134
1.0 INTRODUCTION
This assembly provides three buffered outputs for each input which must be provided from an
external source. Each output is via a unity gain buffer.
This assembly has three inputs and nine outputs.
1.1 INSTALLATION
This assembly may be plugged into any available position.
Remove power from the TM7000. Plug this assembly into the TM7000 being careful to locate the
components on the top side. Be sure inputs J1, J5, and J9 (if applicable) are connected before
plugging the assembly in. Power up the unit.
1.2 OPERATION
There are no operator adjustments for this option.
1.3 SPECIFICATIONS
Table One
Input/Output Level/Load/Frequency Detail
Input J1
Level Up to 1.5 VRMs.
Load
Greater than 100KΩ.
Frequency DC to 1.2 MHz.
Outputs J2, J3, and J4
Level Dependent on input.
Load
600Ω or greater.
Frequency DC to 1.2 MHz.
Input J5
Level Up to 1.5 VRMs.
Load
Greater than 100KΩ.
Frequency DC to 1.2 MHz.
Outputs J6, J7, and J8
Level Dependent on input.
Load
600Ω or greater.
Frequency DC to 1.2 MHz.
Symmetricom, Inc. TM7000 TymMachine TCG/T (Rev D) A-51
