OPTION DESCRIPTIONS
1.4 OPERATION
The Select VERSATILE DISPLAY function Menu is shown in Figure 1. Selecting
TRANSLATOR from this menu by pressing any switch under TRANSLATOR will result in the
Warning Message, Figure 2, being displayed on the LCD.
Select VERSATILE DISPLAY function Menu
Select VERSATILE DISPLAY function
GENERATOR TRANSLATOR TAPE SEARCH
Figure 1
Warning Message
WARNING! This selection will change time
Output and LED display. PROCEED? YES NO
Figure 2
Selecting “YES” will result in the Set-Up Translator Menu Figure 3 being displayed on the LCD. If
“NO” is selected the previous menu and mode remains intact.
Set-Up Translator Menu
Set-up Translator
CODE-AC-dc SLOW CODE
Figure 3
Select DC code by depressing the switch directly below DC. The selected code will be in upper case
letters. When DC is in upper case letters, AC code translation is inhibited. When DC is in uppercase
letters translation of DC code is enabled.
Pressing the
PREV switch will return the LCD Display to that of the Select VERSATILE
DISPLAY function Menu shown in Figure 1.
Pressing the NEXT switch will cause the LCD Display to change to the Select Desired Code Family
Menu as shown in Figure 4.
Select Desired Code Family Menu
Select Desired Code Family
IRIG NASA XR3/2137 OTHER
Figure 4
Symmetricom, Inc. TM7000 TymMachine TCG/T (Rev D) A-35
