Symmetricom TM7000 User Manual

OPTION DESCRIPTIONS
Figure 1
1 2 3 4
E3
E2
E1
J1 J2
S1
1 2 4 8
R15 R17
DC Code
Output
AC Code
Output
Output
Level
Adjust
Mod
Ratio
Adjust
Channel
Selector
ON
OFF
Shown with Channel C (12) Selected
Symmetricom, Inc. TM7000 TymMachine TCG/T (Rev D) A-33
