Synrad Firestar f-Series operator’s manual
Troubleshooting
Tables 4-3 through 4-8 show how Firestar’s signal status changes when remote interlock, over-temperature,
or shutter closed conditions occur (fault conditions are shown in bold type).
Table 4-3 Normal operating condition
LED Indicator LED Status Output Signal Output Status
Remote Interlock Green Interlock Open Open
Temp Green Over Temperature Open
Ready Yellow Laser Ready Closed
Shutter Blue Shutter Open Closed
Lase (tickle active) O Laser Active Open
Lase (if PWM applied) Red Laser Active Closed
Table 4-4 Quick Start Plug or interlock/shutter inputs not connected
LED Indicator LED Status Output Signal Output Status
Remote Interlock Red Interlock Open Closed
Temp Green Over Temperature Open
Ready O Laser Ready Open
Shutter O Shutter Open Open
Lase (tickle inactive) O Laser Active Open
Lase (if PWM applied) O Laser Active Open
Table 4-5 Interlock open condition
LED Indicator LED Status Output Signal Output Status
Remote Interlock Red Interlock Open Closed
Temp Green Over Temperature Open
Ready O Laser Ready Open
Shutter Blue Shutter Open Closed
Lase (tickle inactive) O Laser Active Open
Lase (if PWM applied) O Laser Active Open
