Synrad Firestar f-Series operator’s manual
f200 general specications
Table 3-9 Firestar f200 general specications
Parameter Firestar f200
Output Specications
Wavelength ..............................................................10.2–10.7 microns
Power Output
1, 2
Continuous ......................................................200 Watts
Pulsed
3
............................................................... 250 Watts
Power Stability
4
.......................................................± 10%
Power Stability
5
.......................................................± 6%
Mode Quality ..........................................................M
2
= 1.2 ±0.1
Beam Waist Diameter (at 1/e
2
)
6
........................3.5 ±0.1 mm
Beam Divergence, full angle, (at 1/e
2
) ............4.0 ±0.2 mrad
Ellipticity .................................................................... < 1.2
Polarization ...............................................................Random
Rise Time ....................................................................< 150 µs
Input Specications
Power Supply
Voltage ..............................................................96 ± 2.0 VDC
Maximum Current .........................................36 A
Command Input Signal
Voltage .......................................................................+3.5 to +6.7 VDC
Current (max., continuous) .................................10 mA @ +6.7 VDC
Frequency
7
................................................................ DC–100 kHz
Duty Cycle .................................................................0–100%
Logic Low State (Vmin–Vmax.) .......................... 0.0 to +0.8 VDC
Logic High State (Vmin–Vmax.) .........................+3.5 to +6.7 VDC
* Specications subject to change without notice.
1 This power level is guaranteed for 12 months regardless of operating hours.
2 Minimum 96 VDC input voltage to obtain guaranteed output power.
3 100 Hz, 10% duty cycle, average power as read by laser power meter, then multiplied by 10.
4 From cold start (guaranteed) at 95% duty cycle.
5 After two minutes (typical) at 95% duty cycle.
6 Measured at laser output.
7 Tested at 5 kHz.
