AR 2000 Operator’s Manual
110
Replacement Parts
Replacement parts for the AR Pressure Cell are available from TA Instruments. See the table below when
ordering parts.
Part Number Description
200352.002 Pressure snubber used in manifold kit
200353.001 Three-way ball valve used in manifold kit
200380.001 Wrench Open-End 7/16 & 1/2
200380.002 Wrench Open-End 7/16 & 9/16
200380.003 Wrench Open-End 9/16 & 11/16
400.09199 Wrench (Tommy Bar) used to torque the Rotor Cap into the Pressure Cell
Cup
403001.901 Pressure Cell Assembly
403008.901 Upper Pressure Cell Assembly (with bob and magnet)
403029.901 Manifold Assembly
403032.901 Alignment Magnet used to hold the Rotor Assembly Magnet in place
403040.001 Sorbothane Pad used to mount the Tubing Manifold
403067.901 Safety Pressure Relief Port (with 2500 PSI Rupture Disc)
603.03519 Large Kalrez O-Ring 1.296 I.D. used between Rotor Cap and the Pressure
Cell Cup
603.03557 Kalrez O-Ring 0.208 I.D. used with Thumbscrew on top of Rotor Assembly
Cap
613.03378 Metric Hex Wrench Set (5, 4, 3, 2.5, 2, 1.5 mm sizes)
613.04701 90-degree Angle Pliers used on the Rotor Assembly Locking Nut
