AR 2000 Operator's Manual
83
Using the Sample Cover
Some samples are affected by drafts and general air flow, which can cause drying at the sample edge. To avoid
this, a protective sample cover is provided. The cover should be placed in the up position during sample
loading and trimming: the cover is held in this position by a bayonet fitting that attaches over the coolant
connectors. The cover should be used in the down position during the experimental run.
Figure 7.24
Sample Cover
Up Position (Left ) and Down Position (Right)
WARNING: The sample cover may be hot. Ensure that it is cool before attempting to
raise or remove it.
ATTENTION: Le couvercle échantillon peut être chaud. Assurez-vous qu’il est froid
avant d’essayer de l’enlever.
