Tait TM9100 - Point for Measuring the Power Supply to PA Driver (H5 and H7 Bands)

TM9100 Service Manual Transmitter Fault Finding (50W/40W Radios) 253
© Tait Electronics Limited August 2005
Figure 11.5 Point for measuring the power supply to the PA driver (H5 and H7 bands)
R339
Q308
H5, H7 BANDS
L306
R350
Q306
PAD TOP
MEASUREMENT
POINT ON L306
POINT 1 ON R350
MEASUREMENT
POINT ON R339
POINT 2 ON R 350
