TM9100 Service Manual CODEC and Audio Fault Finding 393
© Tait Electronics Limited August 2005
Figure 13.10 Circuitry under the
CDC TOP can
ITF AUD TAP IN
JUNCTION OF R237 AND R241
JUNCTION OF
R229 AND R232
