TM9100 Service Manual Description 35
© Tait Electronics Limited August 2005
Figure 2.8 Connectors of the radio body (25W radio)
control-head
connector
provision for
external options
connector
provision for
additional
connector
power
connector
auxiliary
connector
RF
connector
internal options
connector
rear view
front view
top view
