TM9100 Service Manual Frequency Synthesizer Fault Finding 175
© Tait Electronics Limited August 2005
Figure 9.2 Synthesizer circuitry under the
SYN TOP can and the 6 V regulator IC606 (top side)
B1 band
H5/H6 bands
Measurement
point on L506
(pin not used)Pin 5 (5-pin device)
Q5004
Q508
Q512
Q507
Q506
Q508
Q512
