TM9100 Service Manual General Information 101
© Tait Electronics Limited August 2005
Service Kit
The service kit contains all the items needed for connecting the radio to
the test equipment. The setting up of the equipment is described in
“Test Equipment Setup” on page 105. The service kit also includes a
service CD and a folder with the necessary service documentation,
including this manual. The CD contains the programming application,
calibration application, and soft-copies of the service and related
documentation. The contents of the service kit are listed in Table 4.2.
Note that the TMAA20-04 cable listed is required only if the test PC is
to be connected directly to the radio for programming purposes.
Note The characters xx below stand for the issue number of the
manual. Only the latest issue of each manual will normally be
available for ordering.
Table 4.2 Contents of service kit (TMAA24-00)
Product code Item
TMAA21-01 Cable (DB15 socket to RJ45 plug plus speaker connector)
TMAA23-02 Cable (50W/40W power connector to banana plugs plus speaker connector)
TMAA20-03 Cable (25W power connector to banana plugs plus speaker connector)
TMAA20-04 Cable (RJ12 socket to RJ45 plug)
TPA-SV-006 Programming cable (DB9 socket to RJ12 plug)
T950-001 Cable (USB1.1 to serial DB9 pin)
TOPA-SV-024 Test unit
MMA-00017-xx Service manual
MMA-00026-xx PCB information
TMAA24-01 Service CD
The following components are included in the service kit, but are used for the TP9100 portable radios only:
TOPA-SV-006 RF cable
TPA-SV-005 Battery eliminator (power supply adaptor)
TPA-SV-007 Programming cable (RJ12 socket to TP9100)
TPA-SV-011 Calibration cable (DB15 socket to TP9100)
