Tait TM9100 - Components of the Radio Body

TM9100 Service Manual Description 25
© Tait Electronics Limited August 2005
Figure 2.2 Components of the radio body
B
cover
G
chassis
C
screw M4x16 (x4)
H
auxiliary connector bung
D
lid assembly
I
screws M4x16 (x2)
E
screw M3x10 (x5)
J
seal
F
main-board assembly
1)
gap pad (50W/40W radio only)
B
C
x4
D
E
x5
F
G
I
x2
H
J
3630z_01
1)
thermal
paste
