TM9100 Service Manual Transmitter Fault Finding (25W Radios) 347
© Tait Electronics Limited August 2005
Figure 12.11 PA driver circuitry under the
PAD TOP can
GATE OF Q306
H5, H6 BANDS
B1 BAND
COMPONENTS
C310, R324, R327
COMPONENTS
C310, R324, R327
GATE OF Q306
