380 CODEC and Audio Fault Finding TM9100 Service Manual
© Tait Electronics Limited August 2005
Figure 13.4 Circuitry under the
CDC BOT can
LO2 BOT CAN
CAN FOR
DIGITAL
BOARD
JUNCTION OF R218 AND IC204CDC AUD TAP OUT
