250 Transmitter Fault Finding (50W/40W Radios) TM9100 Service Manual
© Tait Electronics Limited August 2005
Figure 11.2 Point for measuring the power supply to the PAs (B1 band)
Q310
B1 BAND
Q309
L310
PAF TOP
MEASUREMENT POINT ON L310
