TM9100 Service Manual TMAA02-08 Keypad Microphone 435
© Tait Electronics Limited August 2005
16.6 PCB Information
Note The IPN number on the actual PCB for the keypad microphone
may differ to that shown in the following information.
16.6.1 TMAA02-08 Parts List (PCB IPN 226-00145-04)
C1 018-16100-00 Cap 0603 100n 16vx7r±10%
C2 018-16100-00 Cap 0603 100n 16vx7r±10%
C3 018-16100-00 Cap 0603 100n 16vx7r±10%
C4 015-07220-08 Cap Cer 1206 2u2 16v X7r
C5 018-16100-00 Cap 0603 100n 16vx7r±10%
C6 018-15100-00 Cap 0603 10n 50v X7r ±10%
C7 018-15100-00 Cap 0603 10n 50v X7r ±10%
C8 018-15100-00 Cap 0603 10n 50v X7r ±10%
D1 001-10054-00 Diode SMD BAT54s
D2 001-10054-00 Diode SMD BAT54s
D3 001-10054-00 Diode SMD BAT54s
D4 001-10054-00 Diode SMD BAT54s
DS1 008-10004-00 LED SMD 0603 Green Ultrabright
DS2 008-10004-00 LED SMD 0603 Green Ultrabright
DS3 008-10004-00 LED SMD 0603 Green Ultrabright
DS4 008-10004-00 LED SMD 0603 Green Ultrabright
DS5 008-10004-00 LED SMD 0603 Green Ultrabright
DS6 008-10004-00 LED SMD 0603 Green Ultrabright
J4 240-04020-50 Skt 8w 2x4 Pcb Mtg M/Match
Q2 000-10084-71 Xstr BC847BW NPN SOT323
R1 038-14220-00 Res 0603 2k2 1/16w +-5%
R2 038-14220-00 Res 0603 2k2 1/16w +-5%
R3 038-14220-00 Res 0603 2k2 1/16w +-5%
R4 038-14220-00 Res 0603 2k2 1/16w +-5%
R5 038-13100-10 Res 0603 100e 1/16w ± 1%
R7 038-13100-10 Res 0603 100e 1/16w ± 1%
R8 038-15470-10 Res 0603 47k 1/16w +-1%
R9 038-15470-10 Res 0603 47k 1/16w +-1%
R10 038-15100-10 Res 0603 10k 1/16w +-1%
R11 038-15470-10 Res 0603 47k 1/16w +-1%
R12 038-15470-10 Res 0603 47k 1/16w +-1%
R13 038-13180-00 Res 0603 180e 1/16w ± 5%
R14 038-12100-10 Res 0603 10e 1%
R15 038-15470-10 Res 0603 47k 1/16w +-1%
R16 038-13180-00 Res 0603 180e 1/16w ± 5%
R17 038-13470-00 Res 0603 470e 1/16w +-5%
R18 038-17100-00 Res 0603 1m 1/16w +-5%
R19 038-15120-00 Res 0603 12k 1/16w +-5%
R20 038-14120-10 Res 0603 1K2 1%
R21 038-14100-10 Res 0603 1k0 1/16w +-1%
R22 038-15470-10 Res 0603 47k 1/16w +-1%
R23 038-13180-00 Res 0603 180e 1/16w ± 5%
R24 038-13180-00 Res 0603 180e 1/16w ± 5%
R25 038-13680-00 Res 0603 680e 1/16w +-5%
R26 038-13180-00 Res 0603 180e 1/16w ± 5%
R27 038-13180-00 Res 0603 180e 1/16w ± 5%
R28 038-13180-00 Res 0603 180e 1/16w ± 5%
R29 038-13180-00 Res 0603 180e 1/16w ± 5%
R30 038-10000-00 Res 0603 Zero 0hm 1/16w ± 5%
R31 038-14120-10 Res 0603 1K2 1%
R32 038-13470-00 Res 0603 470e 1/16w +-5%
R33 038-13680-00 Res 0603 680e 1/16w +-5%
R34 038-14100-10 Res 0603 1k0 1/16w +-1%
R35 038-13680-00 Res 0603 680e 1/16w +-5%
R36 038-13680-00 Res 0603 680e 1/16w +-5%
R37 038-13680-00 Res 0603 680e 1/16w +-5%
R38 038-13180-00 Res 0603 180e 1/16w ± 5%
R39 038-13180-00 Res 0603 180e 1/16w ± 5%
R40 038-13180-00 Res 0603 180e 1/16w ± 5%
R41 038-13180-00 Res 0603 180e 1/16w ± 5%
R42 038-13680-00 Res 0603 680e 1/16w +-5%
R43 038-13680-00 Res 0603 680e 1/16w +-5%
R45 038-14180-00 Res 0603 1k8 1/16w
S18 232-00010-29 Sw Tact 3.85 Stem Red Pcb
U1 002-43010-11 IC SMD MSP430F1011AIPW Microc
U2 002-14931-00 IC L4931CD33 3.3v 250Ma Regso8
Y1 274-10010-05 Xtal SMD 32.768KHz Plstc 2MMh
226-00145-04 PCB TMAA-08 K/Pad Micph
