186 Frequency Synthesizer Fault Finding TM9100 Service Manual
© Tait Electronics Limited August 2005
Figure 9.7 Synthesizer circuitry under the
SYN TOP can (top side)
B1 band
H5/H6 bands
Q512
Q512
Junction of
C541 and R547
Junction of
C541 and R547
