4-46
4
HYDRAULIC TANK
DISASSEMBLY AND ASSEMBLY
1. Remove the cab or the canopy.
“Removing the cab”
2. Remove the covers around the tank.
“Removing the covers”
3. Drain the hydraulic oil from the tank (1).
a. Gradually loosen the filler plug to release all internal
pressure beforehand.
b. Loosen the drain plug (6) and drain out the oil.
• Tank capacity: 52 L
4. Disconnect the low pressure hoses from the tank.
5. Disconnect the hydraulic hoses from the tank.
Attach an identification label to each hose for easy re-
assembly.
6. Remove the fixing bolts, suspend the tank and remove
it.
Bolt: ThreeBond #1324
Bolt: 47 N·m
Tank: 36 kg
Installing the hydraulic tank
For installation of the hydraulic tank, follow the same proce-
dure as for removal in the reverse order.
To Next Page
