Takeuchi TB 250 User Manual

2-4
2
SPECIFICATIONS TABLES
SERVICE DATA
SPECIFICATIONS TABLES
Operating mass
Cab kg 4965
Canopy kg 4825
Rated output
29.5/2400
28.4/2400
Bucket capacity
Heaped capacity m
3
0.141
Struck capacity m
3
0.102
Performance
Standard loading mass kg 184
Slew speed min
-1
9.8
Travel speed
1st km/h 2.8
2nd km/h 5.2
Maximum tractive force kN 56.1
Gradeability
% 58
degree 30
Ground Pressure
Cab kPa 28.1
Canopy kPa 27.3
Noise Level
Sound-power level dB(A) L
WA 96
Sound-pressure level dB(A) LPA 77
Machine dimensions
Overall length in transport condition mm 5470
Overall width mm 1840
Overall width Track retracted mm ––
Overall working equipment
height in transept position
Cab mm 2515
Canopy mm 2515
Dimensions of base machine
Overall length of base machine mm 2965
Overall width of base machine mm 1840
Overall width of base machine Track retracted mm ––
Upper structure overall width mm 1690
Upper structure overall width
Left mm 860
Right mm 830
Cab overall length mm 1030
Overall height of base machine mm ––
Slew radius mm 1435
Upper structure rearmost distance from axis of rotation mm 1400
Clearance height under upper structure mm 630
Crawler base mm 1985
Crawler overall length mm 2500
Undercarriage overall width mm 1840
Undercarriage overall width Track retracted mm ––
Track gauge mm 1440
Track gauge Track retracted mm ––
Track shoe width mm 400
Ground clearance of undercarriage mm 335
Net (ISO 14396) kW/min
-1
Net (ISO 9249/SAEJ1349) kW/min
-1
