Takeuchi TB 250 - Page 163

4-58
4
HYDRAULIC PUMP
DISASSEMBLY AND ASSEMBLY
c. Remove the frame.
d. Remove the seal ring.
e. Remove the plate, the guide and the O-rings.
f. Remove the drive gear, the driven gear and the
bushing.




