Takeuchi TB 250 User Manual

2-7
2
SPECIFICATIONS TABLES
SERVICE DATA
Working dimensions
Maximum reach mm 5850
Maximum reach at ground reference plane mm 5710
Minimum level floor radius mm 1835
Maximum digging depth mm 3475
Reach at maximum digging depth mm 2400
Maximum vertical digging depth mm 2725
Maximum height of cutting edge mm 5625
Reach at maximum height mm 3095
Maximum dumping height mm 3990
Reach at maximum dumping height mm 2850
Minimum dumping height mm 1595
Minimum radius of equipment and attachment mm 2170
Minimum radius of equipment at maximum front offset mm 1680
Overall height at minimum radius of equipment and attachment mm 4320
Overall height of equipment at maximum front offset mm 4320
Offset distance of bucket
Left mm 715
Right mm 710/705*
Main structure
Bucket
Type ––
Number of teeth Qty. 4
Hydraulic Cylinder
Boom cylinder
Number of cylinders Qty. 1
Bor
e mm 100
Str
oke mm 690
Arm cylinder
Number of cylinders Qty. 1
Bor
e mm 90
Str
oke mm 750
Bucket cylinder
Number of cylinders Qty. 1
Bor
e mm 80
Str
oke mm 585
Swing cylinder
Number of cylinders Qty. 1
Bor
e mm 90
Str
oke mm 620/615*
Digging force
Maximum digging force
Bucket cylinder kN 37.2
Arm cylinder kN 25.9
Maximum lifting for
ce Boom cylinder kN 26.3
Other attachment (Option) Long arm, Middle arm
*
: Serial No. 125000295 or later
