Takeuchi TB153FR User Manual

76
OPERATION
Machine Operation
Warming Up the Machine
(Hydraulic Oil)
WARNING
Operating the working equipment without
warming up the machine (hydraulic oil)
is dangerous, as response will be slow
and the equipment may move in
unexpected ways. Be sure to sufficiently
warm up the machine.
IMPORTANT: Do not operate the levers
suddenly when the hydraulic oil
temperature is below 20
°C (68°F). The
proper hydraulic oil temperature during
operation is 50 to 80°C (122 to 176°F), but
if operations must be performed at lower
temperatures, heat up the hydraulic oil
to at least 20
°C (68°F).
Normal Warm-up
< TB153FR >
1. Pull the throttle lever to the middle position.
< TB180FR >
1. Turn the throttle controller to the middle
position (B).
2. Run the engine at medium speed for about
5 minutes with no load.
3. Fully lower the safety lock lever to
disengage the lock and raise the pedal
lock to disengage the lock.
4. Lift the bucket from the ground.
5. Extend and retract each of the cylinders
several times with no load.
6. Slew slowly left and right several times.
S2D007
E4D009
D5D014E

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
