Takeuchi TB153FR User Manual

92
OPERATION
Operating Procedures
Traveling Posture
Traveling up slopes
When traveling up slopes at an angle of 15°
or greater, travel in the posture shown in the
diagram above.
Traveling down slopes
When traveling down slopes at an angle of
15° or greater, lower the engine speed and
travel in the posture shown in the diagram
above.
Braking when traveling down slopes
When traveling down slopes, the brakes are
applied automatically when the travel levers
are returned to the neutral position.
Cautions on Traveling on Slopes
WARNING
¡¡
¡¡
¡Never exceed the machine’s stability
capabilities (maximum gradeability – 30°,
lateral tipping angle – 15°). Also note
that when actual working area
conditions are poor the machine’s
stability capabilities may be lower.
¡¡
¡¡
¡When traveling on slopes or grades,
lower the bucket to a height of 20 to 30
cm (8 to 12 in.) off the ground. In
emergencies, lower the bucket to the
ground and stop the machine.
¡¡
¡¡
¡When traveling on slopes or grades,
move slowly in first gear (low speed).
¡¡
¡¡
¡Do not travel down slopes in reverse.
¡¡
¡¡
¡Do not change directions or cross
slopes sideways. First return to a flat
surface then redirect the machine.
¡¡
¡¡
¡On grass, dead leaves, wet metal or
frozen surfaces, the machine may slide
sideways even on very gentle slopes.
Make sure the machine never faces
sideways with respect to the slope.
D5D028E
Braking

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
