Takeuchi TB153FR User Manual

93
OPERATION
Operating Procedures
If the crawlers slip
If the crawlers slip while traveling up a slope,
use the pulling force of the arm to climb the
slope.
If the engine stops
If the engine stops when traveling down a
slope, set the travel levers to the neutral
position, stop the machine, then start the
engine.
Do not open the door while traveling on
slopes
Opening the door while traveling on slopes
is dangerous, as the force required to open
and close the door changes abruptly. Always
keep the door closed when traveling on
slopes.
E4D046
Climbing
D5D029E
Descending
E4D048

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
