3.8.4 Fixed Denomination - FdEn
Value using size and/or SMDS detectors
To choose this option press the MODE key repeatedly to scroll through the available
modes.
Alternatively use the arrow keys to scroll through the available modes.
Press START/STOP to return to the counting display or wait for the display to time out.
Before placing the notes in the note hopper.
Press the DENOM key on the display, the current selected denomination will be
displayed.
Whilst the denomination is shown, press the DENOM key repeatedly to scroll through the
pre-defined list of denominations.
Alternatively, whilst the denomination is shown, use the left or right arrow keys to scroll
through the pre-defined list of denominations.
Alternatively, the numerical keys may be used to specify any denomination.
The size/denomination of each subsequent note is checked against the denomination
table held within the machine.
Place notes to be value counted in the hopper.
The machine will start automatically if AUTO START has been selected, or Press the
START/STOP key if it has not.
1. Display 7. Speed
2. Total 8. Det
3. Mode 9. Clear
4. Batch 10. Right Arrow
5. Start / Stop 11. Denomination
6. Auto 12. Left Arrow
13. Numeric Keypad
1
2
5
67
3
8
4
912 101113
