3.8.6 Value Dispense Mode
Single denomination value dispense mode
The value function of the machine allows you to ‘Value’ a bundle of notes by
denomination, rather than to count the ‘Quantity’. It will also dispense notes by
denomination. It will count downwards from the value entered into the display by the
operator to a zero value, i.e. donE will be shown on the display when finished.
If the dispense amount cannot be completed successfully because there are not enough
notes on the hopper the display will flash the remaining value it needs.
If the dispense amount cannot be completed successfully because the denomination set
is larger than the remaining value required, the display will show NEAR.
Place a new denomination in the hopper, press START/STOP, and input the new
denomination to complete the dispense.
Remove the notes or press CLEAR to go to the dispense amount.
To choose this option press the MODE key repeatedly to scroll through the available
modes.
Alternatively use the arrow keys to scroll through the available modes.
Press START/STOP to return to the counting display or wait for the display to time out.
The machine will only dispense in AdEn if a valid currency table is loaded.
1. Display 7. Speed
2. Total 8. Det
3. Mode 9. Clear
4. Batch 10. Right Arrow
5. Start / Stop 11. Denomination
6. Auto 12. Left Arrow
13. Numeric Keypad
1
2
5
67
3
8
4
912 101113
