Chapter 4: System-Parameters 19
4 System-Parameters
4.1 Overview
System-parameters are parameters just like algorithm-parameters except that they apply to the DSP-
card as such or perhaps to the entire M5000 frame. Each slot has it’s own standard set of parameters,
such as Bypass, but care must be taken, because the parameters have the same numbers in all the
slots. It is the slot# that distinguishes between the parameters, not the actual parameter-number.
4.2 System-Parameters
SYSMIXMODE 0100 0 2 CLS_MIXMODE
SYSBYPASS 0101 0 1 CLS_ONOFF
SYSGIN 0102 0 100 CLS_DB1
SYSCHANMODE 0103 0 3 CLS_CHNLMODE
SYSPHASE 0104 0 1 CLS_POSNEG
SYSIOMODE 0105 (See CLS_IOMODE
♣ SYSCURRATE 0108 Section
SYSMCLOCK 0109 0)
SYSAIN 010a -12 12 CLS_DBF0???
SYSAOUT 010b -18 12 CLS_DBF0???
♣ SYSLOCKSTAT 010c 0 1 CLS_ONOFF
SYSMETERSHOW 0110 0 1 CLS_INOUT
SYSDOTYPE 0111 0 2 CLS_DOTYPE
SYSDOCPY 0112 0 2 CLS_DOCPY
SYSDADEMP 0113 0 1 CLS_ONOFF
SYSR68LEV 0114 0 1 CLS_ONOFF
SYSFSTTRIG 0115 0 1 CLS_ONOFF
SYSMETERL 0401 See section 0
SYSMETERR 0402 See section 0
Parameters marked with a ♣ are read-only.
4.3 VU-Meters
Even though the M5000 front-panel VU-meters only have 10 segments, the meter-information is in
fact far more detailed. The SYSMETERL and SYSMETERR parameters contain the actual meter-
readout in 1/8 dB steps, which is why steps must be taken to produce a useable meter.
4.3.1 Communication
The meters must be polled manually by your software at 1/25 second intervals. You may choose to
poll at a lower rate, although a higher rate won’t result in any improvement. It is recommended that
you poll both the left- and right meters in the same request-packet in order to minimize MIDI-traffic.
The M5000 cannot guarantee to reply with the meters in the same packet, although the packets will
be very close in time. For this reason, your software should be able to handle the left- and right
channels separately.
