APPENDIX C
M5TROUBL
Rev 1.5 Page 15
APPENDIX E
CABLES FOR DIGITAL AUDIO M5000
In order to get a clean and noiseless digital signal flow the cable in which the digital signal is
running has a great influence - especially over longer distances. Here is a list of cables
recommended for digital interfaces by the corresponding manufacturer.
AES/EBU PROFESSIONAL DIGITAL AUDIO
Manufacturer Type
GOTHAM AG R’DORF, SWITZERLAND
NEGLEX – MOGAMI
GEPCO INT’L INC, CHICAGO
CANARE
BELDEN
GAC-2 (AES/EBU), 115ohm, +/-20%
3080 (AES/EBU), 110 ohm
PN5524 – E131675 (ul), CM 24 AWG SHIELDED 75c
105 AES/EBU
9860 (br. Sh.) 9271 (foil. Sh.), 124 ohm (Coaxial)
SPDIF CONSUMER DIGITAL AUDIO
Manufacturer Type
BELDEN
TOSHIBA
SONY
8217 OR 9259, 75OHM (Coaxial, RG-59/U-type)
TOCP174Y (OPTICAL)
POC-15 (OPTICAL)
Use always high-quality, low capacitance cables with fixed impedance (Coaxial), 110
Ω
for
AES/EBU and 75
Ω
for SPDIF. There is no guarantee that it will work properly if an ordinary
microphone cable is used for AES/EBU-communication or ordinary RCA cables for typical
HI-FI equipment.
