MIDI & SMPTE
M5MIDIIN
Rev 1.4 Page 10
TOOLBOX:
Parameter Controller# Parameter Controller#
MIX 10 EQTYPE2 40
INLEV 11 EQFREQ2 41
OUTLEV 12 PWIDTH2 42
INSON 13 NWIDTH2 43
BAL 14 PGAIN2 44
MONO 15 NGAIN2 45
LRSWAP 16 EQON2 46
ID_PHASE 17 EQTYPE3 47
DITHER 18 EQFREQ3 48
DITTYP 19 PWIDTH3 49
MSON 20 NWIDTH3 50
MSANGLE 21 PGAIN3 51
FADECURVE 22 NGAIN3 52
FADER 23 EQON3 53
METER 24 EQTYPE4 54
RANGE 25 EQFREQ4 55
TICKS 26 PWIDTH4 56
HOLD 27 NWIDTH4 57
LDELAY 28 SSLOPE4 58
RDELAY 29 CSLOPE4 59
EQTYPE1 30 PGAIN4 60
EQFREQ1 31 NGAIN4 61
PWIDTH1 32 SGAIN4 62
NWIDTH1 33 EQON4 63
SSLOPE1 34 LPPM 64
CSLOPE1 35 RPPM 65
PGAIN1 36 CORR 66
NGAIN1 37 CORLEG 67
SGAIN1 38 FADVAL 68
EQON1 39
SYSTEM-EXCLUSIVES
System-Exclusives (Sysex for short) is a subset of the MIDI-protocol, which allows software-
developers (who are writing a Mac or PC-based editor) to communicate with the M5000 in a
very technical manner (giving total control over the M5000). The Sysex-documentation is of a
very technical nature, which is why it isn’t described in this manual. The M5000 System-
Exclusive Manual is available at any TC-office.
