G-LEVELS MENU:
When an ADA-1 is installed in the M5000, audio levels must be adjusted in order to get a
clean distortion-free sound. Once analog inputs and outputs are connected, levels can be set.
The output level can be adjusted to provide levels that matches your console or other audio
system. Once a digital signal has been recorded it is often hard to adjust the digital level. In
this menu it is possible to attenuate the digital signal, digital gain is available only in the
optional MD2 algorithim.
PAGE 1:
SOFT DIAL A:
A-IN
-12 dB to +12 dB Sets analog input level.
SOFT DIAL B:
A-OUT
-18 dB to +12 dB Sets analog output level.
SOFT DIAL C:
D-IN
off - 0.0 dB Digital attenuation.
SOFT DIAL D:
MIXMODE
WET+DRY, WET=MAX and WET=MIX
As all factory programs are programmed with a mixed signal between dry and wet signal for musical instruments
(WET+DRY) TC has implemented this feature. When MIXMODE is set to WET=MAX, it automatically sets the
mix level on 100 % meaning that no dry signal is coming through to the effect output. Set MIXMODE
WET=MAX
and all direct signals are "killed" regardless of preset mix settings. This application simplifies the
use of the M5000 when it is used with mixing consoles. WET=MIX means that the dry signal is killed, but the
programmed MIX percentage remains unchanged from the original.
PAGE 2:
DA-DEMP none, 48KHz, 44.1KHz, 32KHz Digital to analog de-emphasis. If you need to
deemphase a pre-emphased signal, choose the
proper samplerate.
ABSPHAS neg, pos With this parameter the absolute phase of the
output signals can be inverted. It affects both the
analog and digital output signals.
R68-LEV off, on When set to
on
the headroom on analog inputs
and outputs are changed to 18 dB according to
the EBU TECHNICAL RECOMMENDATION
R68-1992.
FST.TRG off, on When fast trigger chip is mounted this should be
set to
on
.
MIDI MENU:
For more information about the MIDI menu, please refer to the text module
"INTRODUCTION TO MIDI OPERATION" in the MIDI & SMPTE section.
