GEN. INSTR.
M5GENIN
Rev 1.0 Page 17
CONFIGURATION MENU:
Use DIAL A to select the different options:
SHOW CONFIG (Press DO):
This menu shows (read only) the module configuration for the selected device, the size of the
index ram (
IDX=
), and the size of the
DRAM
(extra memory for sampling).
IDX=
The index ram can be either 32K (standard) or 64 K. If you mount a HIMEM kit
(64K) it will give your DSP card more memory, thus providing longer delay / pre
delay times in some of the algorithms. Exactly where and how much is described
under the respective algorithms.
DRAM
Shows how much dynamic RAM (for sampling) is mounted.
M5000 OPTION (Press DO to view):
Dialing forward you will find all the options available using this software version. If the
option you selected is not installed, the display will appear as follows:
OPTION TIME LEVEL
(Option name)
-- off
Beneath 'OPTION' you see the option names. These options can be installed in 2 ways;
PERMANENTLY or TEMPORARY, i.e. for a limited number of hours. All options
purchased are of course installed permanently, but we invite you to
try an option free of
charge
for a limited time period, usually 100 hours. The installation procedure is described in
CONFIGURATION section, OPTION INSTALLATION. Please refer to this text module for
information about
how to order a temporary demo option
. The LEVEL parameter describes
how many DSP cards in the frame that can run the option simultaneously.
On temporary installations 'TIME' describes the number of hours the option is still available.
On permanently (purchased) installed options the time limit will of course be '
forever
'.
SMPTE MENU:
For more information about the SMPTE menu, please refer to the text module "SMPTE
OPERATION" in the MIDI & SMPTE section.
