APPENDIX C
M5TROUBL
Rev 1.5 Page 10
CONTROLS & DISPLAYS M5000
Power Switch
Rocker type
Device Selector
Selects the DSP to be controlled
Edit Page
Selects next or previous Edit Page
Dials A, B, C, D
Four dials for parameter editing
Program Dial
Control Program- recall, view and store
Do, Undo
Executes and cancels changes made
Program
Selects Program Algorithm Mode
Edit
Selects Edit Parameter Mode
Utility
Selects utility display
Bypass
Bypass of active devices
Load LED
Lit when parameters are updating
Timecode LED
Lit when receiving timecode
MIDI In LED
Lit when receiving MIDI
Digital In LED
Lit when receiving at digital inputs
LAN/SCSI LED
Lit when reading or writing data
Parameter Display
80 character alphanumeric display
Algorithm/Program
Displays algorithm type and program name
Program Number
3 digit program number display
Input Level Meter
Dual 10 segment LED
