ALGORITHMS
M5ALGOIN
Rev 1.7 Page 27
PITCH-1 M5000
The PITCH-1 algorithm is an ultra-fast and high resolution harmony effect with an intelligent
working de-glitcher. The algorithm has two pitch shifters each of which can be panned in the
stereo image. The pitch shifters have independent pitch, filter, feedback and delay settings. It
is also possible to crossfeed from one pitcher to the other whereby existing pitch harmony
build-ups can be made. The diagram below is an addition to the signal flow diagram found in
the "BASIC ALGORITHMS" module, page 2.
EDIT PARAMETERS:
PAGE 1:
MIX 0 - 100 % Sets the mix between dry and wet signal.
100 % = effect signal only. Mix can be
set to 100 % globally in the G-LEVELS-
menu under UTILITY. Set MIXMODE
WET=MAX
and all dry signals are
"killed" regardless of preset mix settings.
INLEV off - 0.0 dB. Sets the level of the input to the program
in 0.5 dB steps. The function of the
