ALGORITHMS
M5ALGOIN
Rev 1.4 Page 12
REVERB-3 M5000
This is a description of the parameters specific to the REVERB-3 algorithm. The REVERB-3
algorithm is very different from the REVERB-1 and 2 algorithms. It is capable of making an
exceptionally clear reverb sound using a very dense and natural sounding reverb tail. DECAY
time can be controlled in four individually adjustable frequency bands. Using DIFFUSE and
the DISTANS (distance) control, sounds can be made in which practically no initial
reflections are heard. Add to this a slight modulation to minimize room interaction with your
source material and you have - REVERB-3.
The diagram below is an addition to the signal flow diagram found in the "BASIC ALGO-
RITHMS" module, page 2.
EDIT PARAMETERS:
MIX 0 - 100 % Sets the mix between dry and wet signal.
100 % = effect signal only. Mix can be
set to 100 % globally in the G-LEVELS-
menu under UTILITY. Set MIXMODE
WET=MAX
and all dry signals are
"killed" regardless of preset mix settings.
INLEV off - 0.0 dB. Sets the level of the input to the reverb in
0.5 dB steps. The function of the control
is to maximize dynamic range. Please
note that this control is positioned after
the input PPM meter, and will not affect
the input PPM reading, also if using an
