91
Model
1kW
Maximum
(A)
Model
1.5kW
Maximum
(A)
Model
1.7kW
Maximum
(A)
Model
2.7kW
Maxi
mum
(A)
Model
3.4kW
Maximum
(A)
10-100 100 10-150 150 10-170 170 10-265 265 10-340 340
20-50 50 20-75 75 20-85 85 20-135 135 20-170 170
30-34 34 30-50 50 30-56 56 30-90 90 30-112 112
40-25 25 40-38 38 40-42 42 40-68 68 40-85 85
60-17 17 60-25 25 60-28 28 60-45 45 60-56 56
80-12.5 12.5 80-19 19 80-21 21 80-34 34 80-42 42
100-10 10 100-15 15 100-17 17 100-27 27 100-34 34
150-7 7 150-10 15 150-11.2 11.2 150-18 18 150-22.5 22.5
300-3.5 3.5 300-5 5 300-5.6 5.6 300-9 9 300-11.5 11.5
600-1.7 1.7 600-2.6 2.6 600-2.8 2.8 600-4.5 4.5 600-5.6 5.6
Table 4-5: Current Programming Range 1kW – 3.4kW
Model
5kW
Maximum
(A)
Model
10kW
Maximum
(A)
Model
15kW
Maximum
(A)
10-500 500 10-1000 1000 10-1500 1500
20-250 250 20-500 500 20-750 750
30-170 170 30-340 340 30-510 510
40-125 125 40-250 250 40-375 375
50-100 100 50-200 200 50-300 300
60-85 85 60-170 170 60-255 255
80-65 65 80-130 130 80-195 195
100-50 50 100-100 100 100-150 150
150-34 34 150-68 68 150-102 102
200-25 25 200-50 50 200-75 75
300-17 17 300-34 34 300-51 51
400-13 13 400-26 26 400-39 39
500-10 10 500-20 20 500-30 30
600-8.5 8.5 600-17 17 600-25.5 25.5
Table 4-6: Current Programming Range 5kW – 15kW
NOTES
1. The power supply can accept values higher by 5% than the table values. However, it is not
recommended to program the power supply over the rated values.
2. Minimum current programming range is 0 Amperes.
