TDK-Lambda GH10-100 - Rear Panel Connections and Controls

8
1.5 Rear Panel Connections and Controls
Refer to Figure 1–4 and Table 1-4 for description of the Rear Panel connections and controls.
Figure 1–4: Rear Panel Connection and Controls
No.
Connection
Description
1 AC Input Connector Connector type:
1kW 1-Phase: 6110.4310 SCHURTER (IEC C16).
1.5kW ~ 3.4kW 1-Phase: PC 5/ 3-G-7,62 PHOENIX CONTACT (shown).
2.7kW ~ 5kW 3-Phase: PC 5/ 4-G-7,62 PHOENIX CONTACT (shown).
10kW ~ 15kW: DFK—PC 16/ 4-ST-10,16 PHOENIX CONTACT (shown).
2 Ground Stud Functional Ground connection: M3x8 Sems screw for Half-Rack, M4x8 Stud
for Full-Rack.
3 DC Output Bus-Bar /
Connector
Bus-bars for 10V to 100V models.
1
3
4
6
5
2
8
7
9
10
11
12
3
1
4
2
6
5
8
7
9
12
11
10
2
6
3
1
2
4
6
5
8
7
9
12
11
10
6
2
2
13
13
13
1
2
3
4
5
6
7
8
9
10
11
12
