9
No.
Connection
Description
150V to 600V Connector type:
GIC 2.5/ 4-G-7,62 PHOENIX CONTACT for Half-Rack models.
IPC 5/ 4-GF-7,62 PHOENIX CONTACT for Full-Rack up to 5kW models.
DFK-IPC 16/ 4-STF-10,16 PHOENIX CONTACT for 10kW ~ 15kW models.
4 Remote Sense Connector A Connector for remote sensing connections.
Connect to the load for regulation of the load voltage and compensation of
load wire drop.
5 Reset Button Set default power supply settings (Factory Reset).
Refer to Table 2-6 & Table 2-7.
Firmware revision 02.105 and below:
Press and hold Reset Button between 5 to 10 seconds, default
communication interface following reset is set to USB.
Firmware revision 02.106 and above:
Press and hold Reset Button up to 5 seconds, default communication
interface following reset is set to USB.
Press and hold Reset Button above 5 seconds, default communication
interface following reset is set to optional communication interface (i.e.
IEEE, MODBUS-TCP or EtherCAT).
* Power Switch must be set to ON position.
6
Paralleling Connectors
Master/Slave connectors, mini I/O type
7 LAN Connector +
Indicators *
LAN interface connector, RJ-45 type + LAN status indicators.
Green LED on RJ45 connector – Link / Activity.
Amber LED on RJ45 connector – Speed. Lit – 100Mbps, otherwise 10Mbps.
Green status indicator (close to RJ45) – Connection active.
Red status indicator (close to RJ45) – LAN fault / Not connected.
8 Serial In Connector RJ-45 type connector, used for connecting power supplies to RS232 or
RS485 port of a computer for remote control purposes. When using several
power supplies in a power system, the first unit Serial-In is connected to the
computer and the remaining units are chained, Remote-Out to Remote-In.
9 Serial Out Connector RJ-45 type connector, used for chaining power supplies to/from a serial
communication bus.
10
USB Connector
USB interface connector, type B.
