67
Keep-Alive:
1800 Seconds (30 minutes)
Auto-Negotiate:
Automatically select network speed VXI-11
Discovery:
Enabled
Password:
None
Multicast DNS:
Enabled
4.7.6 Web Pages
4.7.6.1 Benefits of Web Pages
The web pages are useful for:
• Reading the power supply model, identity, revision and LAN setup information
• Configuring the LAN connection
• Programming and reading the power supply DC output
4.7.6.2 Opening the HOME Page
Once the rear panel green LAN Status LED turns ON, the web page is accessible.
1. Read the IP address from the front panel (Refer to section 4.7.5.1).
2. Open a web page browser program such as Internet Explorer. Enter the power supply IP
address as shown below.
3. Press the Enter key.
The power supply Home page appears. If it does not, refer to Section 4.7.5.3 - LAN Reset to
perform LAN Reset.
4. Alternately, the hostname may be used for addressing the web page as shown below (if the
power supply is set for DHCP/Auto-IP, and if a DNS naming service is running on the
computer). Refer to section 4.7.4.5 for a description of the hostname. Refer to the example
below.
5. The power supply Home page appears. If it does not, refer to Section 4.7.5.3 - LAN Reset to
perform LAN Reset.
