CHAPTER 4: SERIAL RS232/RS485, USB & LAN INTERFACES
4.1 Introduction
This chapter describes the set-up, operation, commands, and communication protocols of the
power supplies via serial communication interfaces: RS232, RS485, or USB, and LAN.
4.2 Configuration
Function Level
Display
Parameter Level
Display
Description
Communication
Interface
INTFC
RS232
RS232
RS485
RS485
USB
USB
LAN
LAN
OPT OPT
Available only if an optional
communication card is installed.
Address
ADR
0…31
0...31
Baud Rate
BAUd
9600…115200
9.6K...115.2K
Language
LANG
SCPI
SCPI
GEN
GEN
IP Address
IP
IP1…IP4
IP1...IP4
MAC Address
MAC
MAC1…MAC6
MAC1...MAC6
LAN Reset
LAN
RESET
R
ESET
Table 4-1: Front Panel Setup
4.2.1 Default Setting
Refer to Table 2-6: Non-Volatile Memory Parameters and Table 2-7: LAN Non-Volatile Memory
Parameters for factory default settings.
4.2.2 Communication Interface Selection
The power supply communication interface can be set to RS232, RS485, USB, LAN, or OPT *.
5. Press the COMM button.
COMM LED illuminates. INTFC message appears on the Voltage display.
6. Rotate the Current encoder to select a required communication interface.
7. Press the Current encoder to accept a parameter.
When the parameter is accepted, the display blinks once.
8. To exit the menu, press the COMM button or the BACK button.
NOTE
* OPT option is available only if an optional communication card (i.e. IEEE, MODBUS TCP or
EtherCAT) is installed.
