6
8 Power / Address Indicator If power supply output is ON, actual output power is displayed.
If power supply output is OFF, power supply address is displayed.
* The address is displayed while Communication menu is active, regardless
of the power supply output state.
9 ext V / ext I Indicators External Voltage / External Current Analog Programming Indicators.
ext V is on if Analog Voltage Programming channel is active.
ext I is on if Analog Current Programming channel is active.
10 REM Indicator REMOTE indicator.
REM is on if power supply is controlled by a remote communication
(RS232/485, USB, LAN, OPTional).
11 RS Indicator Recommended Standard indicator.
RS232 or RS485 communication type is selected.
12 USB Indicator Universal Serial Bus indicator.
USB communication type is selected.
13 LAN Indicator Local Area Network indicator.
LAN communication type is selected.
14 OPT Indicator Optional communication type indicator.
Optional communication type is selected.
15 TRIG Indicator Trigger Indicator.
TRIG is on if the trigger-in is enabled and initialized.
Power supply is ready to receive trigger-in signal.
16 Active Memory-Cell
Indicator
Display active memory cell.
1,2,3,4 – A sequence is loaded from cells 1,2,3 or 4
_ - A sequence is loaded from a PC
The Indicator is blinking if a sequence is running.
Table 1-2: Front Panel Display and Indicators
