11
No.
Connection
Description
5 LOC/REM MON Output for indicating if the unit is in Local (digital) or Remote (analog)
programming mode.
6 LOC/REM SELECT Input for selecting between Local (digital) or Remote (analog) programming
of the output Voltage and Current.
7 IPGM Input for Remote (analog) voltage/resistance programming of the Output
Current.
8 VPGM Input for remote (analog) voltage/resistance programming of the Output
Voltage.
9
NOT USED
10 ENA_IN Enable / Disable the power supply output by dry-contact (short / open) or
voltage source. Selectable signal polarity.
11
COM
COMMON. Return for all signals.
12
COM
COMMON. Return for all signals.
13
COM
COMMON. Return for all signals.
14
COM
COMMON. Return for all signals.
15
NOT USED
16
NOT USED
17
COM
COMMON. Return for all signals.
18
COM
COMMON. Return for all signals.
19 ILC Enable / Disable the power supply output by dry-contact (short / open) or
voltage source.
20
Programmed Signal 2
General Purpose Open Drain Port 2.
21
Programmed Signal 1
General Purpose Open Drain Port 1
22 Trigger In Power supply trigger input for sequencer operations. Positive edge
triggered, pulse width: min. 10usec.
23
Trigger Out
Trigger output, positive edge, pulse width: min. 100usec.
24
NOT USED
25
I_MON
Output for monitoring the power supply output Current.
26
V_MON
Output for monitoring the power supply output Voltage.
Table 1-5: J1 Connector Terminals and Functions
