58
Default
Gateway
Address set by DHCP or static
DNS Server Address set by DHCP
LAN Reset Reset configuration
LAN PROTOCOLS
TCP LAN packets follow Transmission Control Protocol
IPv4 Internet Protocol version 4
INSTRUMENT PROTOCOLS
VXI-11 Supports Core channel, not Abort or Interrupt channels
VISA VXI-11 compliant, uses RPC and Portmapper, SCPI commands
TCP Sockets Send SCPI commands to port 8003
UDP Sockets Send SCPI commands to port 8005
VXI-11
Discovery
Find connected instruments
SNMP Ping
Server
Verify LAN connection to instrument
HTTP Web page server with Java scripts
COMMANDS
SCPI SCPI 1999 compliant command set, measure and status
IEEE-488.2 Condition and event register tree
MULTIPLE CONTROLLERS
Single Client
Setting
Only one may be open at a time:
Web Page (login as 'admin'), VISA or TCP sockets
Multiple Client
Setting
Up to two TCP or UDP sockets may be open at a time
WEB PAGES
Multiple users Multiple web pages can be open at the same time
Identity Identify power supply model, serial number, revision, etc.
LAN
Configuration
View and set LAN configuration
Active Control
GUI
Program and read output settings
Send
Commands
Send SCPI commands, read errors
Help Link to TDK-Lambda web sites
