94
OUTPut:PROTection:DELay
Sets the delay time between the programming of an output change that produces a CV or CC
status condition. This command applies to UVP and Foldback functions.
SCPI Command Syntax OUTPut:PROTection:DELay <NRf+>
GEN Command Syntax FBD
Parameters 0.1 to 25.5|MIN|MAX (step 0.1s)
Unit S (second)
*RST Value 0mS
Examples OUTPut:PROTection:DELay 2E-1
Query Syntax OUTPut:PROTection:DELay?
Returned Parameters <NR3>
OUTPut:ILC:MODE
Selects the mode of operation of the Remote Inhibit protection. In OFF mode the power supply
ignores J3-4 (ILC) status.
SCPI Command Syntax OUTPut:ILC:MODE <CRD>
GEN Command Syntax RIE
Parameters 0|OFF 1|ON
*RST Value OFF
Examples OUTPut:ILC:MODE ON
Query Syntax OUTPut:ILC:MODE?
Returned Parameters ON/OFF
OUTPut:TTLTrg:MODE
Sets the operation of the Trigger Out signal to either OFF, Function Strobe or Trigger mode.
Programming Mode NONE, FIX:
• In TRIG mode, trigger is generated when output status changes.
• In Function Strobe mode, an output pulse is generated automatically any time an output
parameter such as output, voltage or current is programmed.
Programming modes LIST or WAVE:
• In TRIG mode, trigger is generated when LIST or WAVE is completed.
• In Function Strobe mode, an output pulse is generated automatically any time a step is competed.
The power supply Trigger Out signal is available at J3-3 connector on the rear panel.
SCPI Command Syntax OUTPut:TTLTrg:MODE <CDR>
GEN Command Syntax None
Parameters TRIG| FSTR|OFF
*RST Value OFF
Examples OUTP:TTLT:MODE TRIG
Query Syntax OUTP:TTLT:MODE?
Returned Parameters <CRD>
