84
Figure 59: Settings: Alarm Test Screen
9. Fault each additional alarm as described in the following table and ensure that it is marked as
alarm.
Sensor Testing Process
Door/Window Open and close the door or window.
Motion Detec-
tor
Avoid the motion detector’s view for three minutes after arming the system,
then walk in front of it.
Smoke Detec-
tor
Press and hold the sensor’s “Test” button until the siren sounds, approx-
imately ten seconds.
Glass Break
Detector
Use a glass break simulator.
Key Fob Arm and disarm the system with the key fob.
Key Pad Arm and disarm the system with the key pad.
Table 10: Sensor Testing Operations
The TouchScreen notes that each sensor communicated an event to the TouchScreen and
initiated an alarm.
10. After all the alarms have been faulted and the system has noted it, tap Disarm.
11. Tap Next.
The Review Alarms screen is displayed showing a history of the zones in your system.
