9.2. SERVICE MENU CONFIGURATION
The configuration procedure is invoked when the machine is in standby mode.
Simultaneously press the ENTER, ↑, CLEAR keys. The following prompt appears on the LED
display:
ENTER PASSWORD:
To access the procedure, type in the password 2501 which protects against unauthorized access and
press “Enter” to confirm. To enter the password, increase or decrease the displayed value using the
↑ and ↓ keys, or use the +/- GOAL keys to scroll through and modify the individual digits.
At this point there are two options available:
↑ = Tech Config
↓ = Troubleshooting
Press numeric key ↑ to access the menu for configuring technical parameters; the machine display
will begin showing the current configuration, structured as in the diagram below:
• Configuration
TECHNICAL
CONFIGURATION
ERRORS LOG
KEY READER
VERS.
LOW KIT
PARAM.
UPDOWN
SETTINGS
OPERATING
DATA
LOW KIT
MENU
BOOT
VERSION
STANDARD
SETTINGS
HIGH KIT
VERSION
Scroll through the parameter list using the + or – speed keys to move the next or previous
parameter.
To modify a parameter value, it is necessary to press the ENTER key: when the current parameter
value starts to blink, press the CLEAR key to erase the current value and then use the number keys
to enter the desired new value. Save the changes made by pressing the ENTER key.
To cancel the operation, press the CLEAR key for a few seconds.
The various parameters are described below.
