2.7. WIRING
TRM-32: TGS Cable
Display Board – TGS reader
Display Board
CN3
Signal Color TGS reader
CN1
1 +12 Vdc power supply Yellow 1
3 Rx White 8
5 Tx Green 7
9 Gnd Brown 3
CU133: Cable connecting upper and lower assemblies
Display board – AT driver board
Display Board
CN7
Signal Color AT driver board
J3 or J4
1 Gnd +12 Vdc Black J3 – pin 2
2 Not connected - -
3 485 Tx/Rx + White/brown J4 – pin 7
4 485 Tx/Rx - Brown J4 – pin 8
5 +12 Vdc Red J3 – pin 6
6 Digital Gnd Light orange J4 – pin 6
7 Emergency Orange J3 – pin 9
8 Reset Purple J3 – pin 10
ATTENTION: The pins 1-2-3-4-5 on the J4 connector are engaged by cables not connected
anywhere.
The pins 3-4, 3-12, 6-11 and 7-8 are short-circuited each other.
CU135: HS / cardio receiver board cable
Display board - HS / cardio receiver board
Display Board
CN9
Signal Color HS / receiver
board
HD4
1 +5 Vdc power supply Brown 2
4 Pulse out White 3
5 Reference Green 1
