KINESIS ONE: Service & Maintenance Manual rev. 2.1
Page 6.10
Figure 6.4-6
4. Pass the cable through the less deep hole on
the internal side of the cam.
Figure 6.4-7
5. Fix the crimped end of the cable inside the
cable-retainer and house it in the cam, as
shown in figure.
Continued on following page →
