UPS EVO DSP PLUS Modular 19 User’s manual
Table 5-2: Control Keys
Control Key
Description
Power On/Off
Turn ON or Turn OFF the UPS.
Table 5-3: Audible Alarm
UPS condition
Description
Power ON/OFF
Buzzer sounds 2 seconds.
Battery Mode
Buzzer sounds every 2 seconds.
Low Battery
Buzzer sounds every 0.5 seconds.
UPS Alarm
Buzzer sounds every 1 second.
UPS Fault
Buzzer continuously sounds.
5.2 LCD Display Description
5.2.1 Initial Screen
Upon powering on, the UPS will execute POST (Power-On Self-Test). The initial screen will remain approximately
5 seconds as shown below.
Figure 5.2 – Initial Screen
